Specifications
Function | Measuring range | Best accuracy | Resolution |
---|---|---|---|
MΩ | 400k/4M/40M/400M/4000MΩ | ±(3%+4) | 0.001MΩ |
Rated voltage | 125/250/500V | ||
ACV/DCV | 600V(AC/DC Automatic detection) | ±(3%+2) | 1V |
Ω(Continuity) | 4000Ω | ±(3%+3) | 1Ω |
Ω | 40Ω | ±(3%+10) | 0.01Ω |
Rated current | 1.0~1.2mA |
Short-circuit detection | Below 2mA |
Live circuit detection | At 30V AC/DC or more, inhibits test, buzzer sounds and ALARM indicator lights up |
Battery | R6P(AA battery)1.5Vx6 |
Size/Mass | H170×W142×D57mm/Approx. 600g |
Safety standard | IEC61010 CAT.Ⅲ 600V |
