Specifications
Function | Measuring range | Best accuracy | Resolution |
---|---|---|---|
DCA | 60/400A | ±(2.0%+5) | 0.01A |
ACA | 60/400A | ±(2.0%+5) | 0.01A |
Sampling rate | 2 times/sec. |
Bandwidth | 45-400Hz |
Display | 6000 |
Clamp diameter/Conductor size | 25mm/10×26mm |
Battery | LR03×2 |
Battery life | Approx. 35 hrs. |
Size/Mass | H145×W54×D31mm/Approx. 120g |
Safety standards | IEC61010 CAT.Ⅲ300V |
In the peak hold mode, the measuring range is fixed at 400A.
