Specifications
| Voltage | 110V, 220–240V AC 50/60Hz | |||
|---|---|---|---|---|
| Power Consumption | 85W | |||
| Power Cord Length | 1.5m | |||
| Temperature Setting Range | 250–450°C | |||
| Ripple temperature | ±5˚C (unloaded) | |||
| Insulation Resistance | Over 100MΩ (500V DC) | |||
| Accessories | Soldering Iron Tip (PX-60RT-B) | |||
Control Unit
| Output Voltage | 110V, 220–240V AC | |
|---|---|---|
| Dimensions | 100(W) × 57(H) × 85(D)mm | 48(W) × 31(H) × 130(D)mm |
| Weight | 266g | 75g |
Soldering Unit
| Voltage / Consumption | 110V, 220–240V AC /80W |
|---|---|
| Ground Resistance | Less than 2Ω |
| Leak Voltage | Less than 2mV |
| Heater | Ceramic heater |
| Cord Length | 1.2m |
| Length | 195mm (with PX-60RT-B) |
| Weight | 41g (with PX-60RT-B) |
