Specification
| product or component type | Switched socket |
|---|---|
| device application | Power supply |
| device presentation | Complete product |
| outlet poles configuration | 3P with shutter |
| colour tint | Dark grey |
| type of packing | Flow-pack |
| rated current | 15 A socket-outlet |
|---|---|
| [Ue] rated operational voltage | 250 V AC 50/60 Hz |
| socket number | 1 |
| outlet standard description | With earthing contact |
| outlet standard | British BS 546 |
| number of gangs | 1 gang |
| pilot light | LED |
| service life in cycles | 20000 cycles |
| electrical durability | 5000 cycles |
| connections – terminals | Screw terminal |
| material | Polycarbonate: grid plate Polycarbonate: surround |
| surface finish | Glossy |
| surface treatment | Painted cover plate |
| device mounting | Surface |
| fixing mode | Screw |
| height | 86 mm |
| width | 86 mm |
| depth | 32.6 mm |
| IP degree of protection | IP20 |
|---|---|
| ambient air temperature for operation | -5…45 °C |
| ambient air temperature for storage | -5…60 °C |
| standards | MS 1577 BS 546 SS 472 |
| product certifications | SIRIM |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 91.0 g |
| Package 1 Height | 3.2 cm |
| Package 1 width | 8.6 cm |
| Package 1 Length | 8.6 cm |
| Unit Type of Package 2 | CAR |
| Number of Units in Package 2 | 10 |
| Package 2 Weight | 910.0 g |
| Package 2 Height | 9.5 cm |
| Package 2 width | 19 cm |
| Package 2 Length | 19.5 cm |
