Specification
product or component type | Switched socket |
---|---|
device application | Power supply |
device presentation | Complete product |
outlet poles configuration | 3P with shutter |
colour tint | White |
type of packing | Flow-pack |
rated current | 15 A socket-outlet |
---|---|
[Ue] rated operational voltage | 250 V AC 50/60 Hz |
socket number | 1 |
outlet standard description | With earthing contact |
outlet standard | British BS 546 |
number of gangs | 1 gang |
pilot light | LED |
service life in cycles | 20000 cycles |
electrical durability | 5000 cycles |
connections – terminals | Screw terminal |
material | Polycarbonate: grid plate Polycarbonate: surround |
surface finish | Glossy |
surface treatment | Painted cover plate |
device mounting | Surface |
fixing mode | Screw |
height | 86 mm |
width | 86 mm |
depth | 32.6 mm |
IP degree of protection | IP20 |
---|---|
ambient air temperature for operation | -5…45 °C |
ambient air temperature for storage | -5…60 °C |
standards | MS 1577 BS 546 SS 472 |
product certifications | SIRIM |
Unit Type of Package 1 | PCE |
---|---|
Number of Units in Package 1 | 1 |
Package 1 Weight | 91.0 g |
Package 1 Height | 3.2 cm |
Package 1 width | 8.6 cm |
Package 1 Length | 8.6 cm |
Unit Type of Package 2 | BB1 |
Number of Units in Package 2 | 10 |
Package 2 Weight | 955.0 g |
Package 2 Height | 9.5 cm |
Package 2 width | 19 cm |
Package 2 Length | 19.5 cm |
Unit Type of Package 3 | CAR |
Number of Units in Package 3 | 60 |
Package 3 Weight | 6230.0 g |
Package 3 Height | 21 cm |
Package 3 width | 30 cm |
Package 3 Length | 39.5 cm |
