Specifications
Resistance (Ω) | 20Ω/200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ/2000MΩ | ±(0.8%+1) |
Capacitance (F) | 200pF/2nF/20nF/200nF/2uF/20uF/200uF/2mF/20mF | ±(0.5%+10) |
Features | ||
Display count | 2000 | |
Manual range | √ | |
Diode | √ | |
Transistor | √ | |
Continuity buzzer | √ | |
Low battery indication | √ | |
General Characterisitics | ||
Power | 9V battery (6F22) | |
Display | 61mm x 32 mm | |
Product color | Red and grey | |
Product net weight | 310g | |
Product size | 172mm x 83mm x 38mm | |
Standard accessories | Battery, test leads with alligator clips, holster | |
Standard individual packing | Gift box, English manual | |
Standard quantity per carton | 20pcs | |
Standard carton measurement | 450mm x 330mm x 340mm (0.099CBM per standard carton) | |
Standard carton gross weight | 9.6kg |
