Specifications
| Sensor | Uncooled focal plane |
| Temperature range | 30˚C~45˚C |
| Resolution | 0.1˚C |
| Accuracy | ±0.5˚C @1m |
| Minimum measuring distance | 15cm |
| Temperature measurement response time | ≤500ms (95% of reading) |
| Pixel of thermal imagery | 19200 (160×120) |
| Pixel dimemsions | 12μm |
| Palettes | Iron red, rainbow, white, black, red, lava, high-contrast rainbow |
| Bandwidth of infraed spectroscopy | 8~14μm |
| Field of view (FOV) | 56°(H) × 42°(V) |
| Instantaneous field of view (IFOV) | 6mrad |
| Thermal imaging sensitivity | ＜50mk |
| Frame rate | ＜9Hz |
| Temperature display | Center temperature measurement and high temperature tracking (default) |
| Image format | BMP |
| Buttons | 10 buttons: POWER button, Camera button, Return button, Navigation buttons, SET button, Browsing button, LED lighting button |
| Image modes | Thermal imagery, digital camera (visible light), fushion |
| Temperature measuring point | Besides central point, 3 temperature measuring points can be added |
| Visible light | √ |
| Resolution of visible light | 640×480 |
| Display resolution | 320×240 |
| Mixed setting | 0% (total visible light), 25%, 50%, 75%, 100% (total thermal imagery) |
| PC analysis software (PC) | √ |
| Real-time image transmission | √ (PC software image projection) |
| Data communication | Type-C USB |
| Auto power off | Selectable (5min, 10min, 30min), 30min auto power off (default) |
| Service time | ≧6 hours |
| Charging time | ≦5 hours |
| Charging voltage/current | 5V/2A |
| Image storage | Micro SD card |
| General Characteristics | |
| Power | A single Li-ion 3.7V/5000mAh 26650 battery |
| Display | 2.8″ TFT LCD |
| Product color | Red & grey |
| Product size | 236mm x 75.5mm x 86mm |
| Standard accessories | Manual, Type-C USB cable, 16GB TF card |
| Standard carton gross weight | 2.2kg |
