Specifications
| Display type | Green LD |
| Laser type | 4V1H |
| Laser points | 6 |
| Laser wavelength | 510~515nm |
| Light source | ≤1mW |
| Laser class | 2 |
| Expanded Angle | H130°/V110° |
| H/V accuracy | ± 3mm@10m |
| Self-leveling range | 3° (±0.5°) |
| Self-leveling method | Gravity pendulun magnetic damping |
| Self-leveling time | ≤5s |
| Working distance | Line 20m, point 25m@300lux |
| Operating time | >5h (all lasers on) |
| Operating temperature range | -10°C to 40°C |
| Storage temperature range | -20°C to 60°C |
| GENERAL CHARACTERISTICS | |
| Power | 3.7V Li-ion battery 4000mAh |
| Product net weight | Around 1kg |
| Product size | 190mm x 132.5mm x 127mm |
| Standard accessories | Safety goggles, adapter, mark ruler, Li-ion battery, strap, English manual |
| Standard individual packing | Gift box, tool box |
| Standard quantity per carton | 4pcs |
| Standard carton measurement | 440mm x 330mm x 260mm |
