Specification
range | Vivace |
---|---|
product or component type | Switch |
device short name | KB32 |
device application | Lighting |
device presentation | Complete mechanism |
switch function | 2-way |
---|---|
actuator | Rocker |
number of gangs | 2 gangs |
colour tint | White |
material | Polycarbonate: grid plate Polycarbonate: surround Polycarbonate: base |
projecting depth | 8 mm |
device mounting | Flush |
mounting support | Wall mounted |
fixing mode | By screw M3.5 |
fixing center | 60.3 mm |
embedding depth | 35 mm |
rated current | 16 AX at 250 V AC, inductive 16 AX at 250 V AC, fluorescent |
[Ue] rated operational voltage | 250 V AC |
network frequency | 50 Hz |
contacts material | Brass and phosphor bronze |
connections – terminals | Pillar terminal |
terminal identifier | L2 COM L1 |
tightening torque | 0.4 N.m |
clamping connection capacity | 2.5 mm² |
width | 87 mm |
height | 87 mm |
standards | SS 227 MS IEC 60669-1 IEC 60669-1 |
---|---|
ambient air temperature for operation | -5…40 °C |
relative humidity | 0…95 % |
environmental characteristic | Indoor use |
Unit Type of Package 1 | PCE |
---|---|
Number of Units in Package 1 | 1 |
Package 1 Weight | 72.0 g |
Package 1 Height | 4 cm |
Package 1 width | 8.5 cm |
Package 1 Length | 8.5 cm |
Unit Type of Package 2 | PAL |
Number of Units in Package 2 | 1600 |
Package 2 Weight | 162000.0 g |
Package 2 Height | 99 cm |
Package 2 width | 80 cm |
Package 2 Length | 120 cm |
Unit Type of Package 3 | BB1 |
Number of Units in Package 3 | 8 |
Package 3 Weight | 662.0 g |
Package 3 Height | 9.5 cm |
Package 3 width | 15 cm |
Package 3 Length | 19 cm |
