Specification
| range | Vivace |
|---|---|
| product or component type | Switch |
| device short name | KB34 |
| device application | Lighting |
| device presentation | Complete product |
| Additional switch application | Switch |
| switch function | 1-way |
|---|---|
| actuator | Rocker |
| number of gangs | 4 gangs |
| colour tint | White |
| material | Polycarbonate: grid plate Polycarbonate: surround Nylon: base |
| surface finish | Glossy |
| surface treatment | Untreated |
| type of packing | Plastic bag |
| quantity per set | 1 |
| projecting depth | 8 mm |
| device mounting | Flush |
| mounting support | Wall mounted |
| fixing mode | By screw M3.5 |
| fixing center | 120.6 mm |
| embedding depth | 35 mm |
| rated current | 16 AX at 250 V AC, inductive 16 AX at 250 V AC, fluorescent |
| [Ue] rated operational voltage | 250 V AC |
| network frequency | 50/60 Hz |
| connections – terminals | 8 pillar terminal |
| terminal identifier | COM L1 |
| tightening torque | 0.4 N.m |
| clamping connection capacity | <= 2.5 mm² for rigid or stranded cable(s) |
| wire stripping length | 12 mm |
| width | 146 mm |
| height | 86 mm |
| depth | 36 mm |
| standards | IEC 60669-1 SS 227 MS IEC 60669-1 |
|---|---|
| ambient air temperature for operation | -5…40 °C |
| relative humidity | 0…95 % |
| operating altitude | 0…2000 m |
| environmental characteristic | Indoor use |
| IP degree of protection | IP20 |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Weight | 136.0 g |
| Package 1 Height | 3.1 cm |
| Package 1 width | 8.6 cm |
| Package 1 Length | 14.6 cm |
| Unit Type of Package 2 | P12 |
| Number of Units in Package 2 | 1000 |
| Package 2 Weight | 222000.0 g |
| Package 2 Height | 120 cm |
| Package 2 width | 80 cm |
| Package 2 Length | 120 cm |
| Unit Type of Package 3 | CAR |
| Number of Units in Package 3 | 50 |
| Package 3 Weight | 7500.0 g |
| Package 3 Height | 21 cm |
| Package 3 width | 31.5 cm |
| Package 3 Length | 50 cm |
